• Linear acceleration
Diapason : 0 - 20 000g
Dimensions: 50 * 50 * 50 mm
Centrifuge.
For testing robustness of design / in production
• Leakage test
2.1 He - small leakage
Dimensions - 100 * 100 * 70 mm
2.2 SF6 – small / big leakage
Dimensions - 35 * 25 * 15 mm
• Vibration test
Vibrations - 10 - 100 Hz
Dimensions - 250 * 250 * 40 mm - 2 places
• Solderabiltiy test
Temperature + 230 °C
• Heat treatment
Thermal shock test - checking roubustness of design, manufacturing
test
Dimensions : 750 * 730 * 650 mm Temperatures : -65 +300 °C
500 * 480 * 370 mm - till +150 °C
500 * 650 * 660 mm - till +250 °C
Heat treament ( smooth heating )
Dimensions : 750 * 730 * 650 mm - till +300 °C
• Thermal cycling, thermal shock, testing for exposure to high humidity and temperature shifts
Big transparent window for visual process controlling during
functional&electric test/load.
For testing functionality and parameters measurements under hursh conditions.
Dimensions : 720 * 600 *850 mm
-30 ºС ÷ +125 ºС ; 10 % ÷ 95 % humidity
Electrical connections through two ports
• Thermo-electric training (robust test – design / production)
Dimensions : 500 * 300 * 680 mm
Temperature : till +125 °C , 4 supplies ( 30V , 5A) , sin generators
Dimensions: 260 * 580 * 1000 mm
Temperature : till +125 °C , 12 supplies ( 30V , 5A) , impulse generators
• Thermo-chambers for electric parameters measurements
Dimensions: 650 * 570 * 630 mm
Temperatures : -65 °C + 130 °C
• Accelerated aging test chamber
High pressure, temperature, humidity.
Accelerated test (several years in weeks) for whole design or for part of solution
Dimensions : Ø 45 * 50 mm
• EMI protected measurment room Siemens & Matsushita
Underground (under the ground level)) , isolation transformer
Room : 2400 * 2400 * 2400 mm
For testing and production HF or sensitive devices
• Fast engineering evaluation hot/cold air ( -40 + 120 °C ) under electrical connection
• Study of structures
Oblique cuts, layer-by-layer etching, surface analysis (optical)
• Thermography
IR search for hot spots on the board/device under load.
• Noise, vibration, infrasound and ultrasound measurements
- sound level measurements with frequency characteristics A B C
- sound pressure level measurements in the frequency range 2 Hz ... 18 kHz
- measurement of octave bands in the frequency range from 2 Hz to 8 kHz in free and diffuse fields
- measurement of mean square values of vibration acceleration and vibration velocity
• Static discharge test 0 - 2400 V with possibility to connect any capacitor -resistive network.
|
